Switch Multi PoE+/++ de 19"

Inquiry
Switch Multi PoE+/++ de 19"

Switch Multi PoE+/++ de 19"

  • Switch rentable Gigabit Ethernet de 19" con 28 puertos, 24 puertos PoE+ 10/100/1000Base-T (802.3at) y un consumo de 370 W
  • Amplias funciones como QoS, VLAN, RSTP, etc.
  • Bajo coste total de propiedad (TCO) gracias a un diseño energéticamente eficiente
  • 4x ranuras SFP 100/1000Base-X (sin codificar)
  • Gestión de red mediante navegador web
  • Gestión y disposición de PoE mejoradas mediante 802.3az (Energy Efficient Ethernet)



Download
All downloads
Data sheet MS400835M
Data sheet MS400970M
User Manual MS400835M
Quick Start Guide MS400970M
Quick Start Guide MS400980M
Quick Start Guide MS400981M
Revit file (rfa) MS400970M
Secure Download
Firmware MS400835M v1.0.0.16
Firmware MS400970M v1.3.1j
EoS - Firmware MS400980M V1.3.1j
EoS - Firmware MS400981M V1.3.1j
Firmware EOL MS400834M 1.2.1433
Firmware EOL MS400834M 1.2.1261
Firmware EOL MS400830M 1.58
LV Text Multi PoE+ Switches
Detail information
Description
Description

The high-performance 28-port Gigabit Ethernet switch is specially designed for use in networks in which Power-over-Ethernet functionality is used. All 24 10/100/1000Base-T copper ports offer PoE according to IEEE802.3af and IEEE802.3at standards.



This allows end devices connected to the network port to be supplied with a power of up to 30 W per port cost-effectively and without additional cabling. The total power output of the switch is up to 370 W.

The 28 port switch has 4x 100/1000X ports. This enables a direct connection to a GBE fiber optic backbone via standard SFP transceivers. Switches located further away can be cascaded via fiber optic cables.

All network ports are accessible from the front of the device, making patching much easier. The switch is equipped with an integrated smart management (via web browser). In addition, the status information can be read out via SNMP. The GBE switch also supports a wide range of functions such as QoS, VLANs, STP/RSTP, loop protection, IGMP snooping, SNMP traps and much more.

The device is powered with 100..230 VAC via a connector on the rear of the device.

Items

Products
Products
Products

MS400835M


Product is available

Order offer

MS400835M

28-Port 10G Switch 19" PoE+, 24x10/100/1000T PoE+, 4x 1/10G-X SFP+-slots, int. 110/230VAC (C14), 370W, managed

Products

MS400992M


Product is available

Order offer

MS400992M

28-Port 10G Multi PoE+ L3 Switch 19", 4x 1/10GBase-X SFP+-Slots, managed L3, 24x 10/100/1000Base-T PoE+, OOB-Port (RJ-45), int. 100~240VAC (C14), console port (RJ-45)

24x RJ-45, 4x SFP+ Slots, 1x Console RJ-45, 1x OoB RJ-45, 1x USB-A, 1x SV

Accessories
Accessories

MS400992-AC


Product is available

Order offer

MS400992-AC

Power module 230VAC for MS400992M for red. 100~240 VAC, 50/60 Hz, 370W

Accessories

MS400994-AC


Product is available

Order offer

MS400994-AC

Power module 230VAC for MS400994M for red. 100~240 VAC, 50/60 Hz, 150W

End of Life / Out of product range
End of Life / Out of product range

MS400834M

show alternative

Product reached his Life-Time

Order offer

MS400834M

End of Life / Out of product range

28-Port GbE Switch 19" 1HE PoE+ 24x10/100/1000T PoE+, 4x 100/1000X SFP-Slots, int. 110/230VAC (C14), 420W, managed

NIL --> MS400835M

hide alternative

MS400835M

hide alternative

Product is available

Order offer

MS400835M

hide alternative

28-Port 10G Switch 19" PoE+, 24x10/100/1000T PoE+, 4x 1/10G-X SFP+-slots, int. 110/230VAC (C14), 370W, managed

End of Life / Out of product range

MS400830M

show alternative

Product reached his Life-Time

Order offer

MS400830M

End of Life / Out of product range

24 Port Gigabit Ethernet Switch, 20 Port 10/100/1000Base-T PoE + 4 Port TP/(100M/1G SFP) Combo Smart Management 19" 1U

NIL -> MS400835M

hide alternative

MS400835M

hide alternative

Product is available

Order offer

MS400835M

hide alternative

28-Port 10G Switch 19" PoE+, 24x10/100/1000T PoE+, 4x 1/10G-X SFP+-slots, int. 110/230VAC (C14), 370W, managed

End of Life / Out of product range

MS400980M

show alternative

Product reached his Life-Time

Order offer

MS400980M

End of Life / Out of product range

28-Port 10G L2/L3 Switch 19" PoE+, 4x 1/10GBase-X SFP+-Slots, managed, 24x 10/100/1000Base-T PoE+, int. 100~240VAC (C14), console port (RJ-45)

EoL -> MS400992M

hide alternative

MS400992M

hide alternative

Product is available

Order offer

MS400992M

hide alternative

28-Port 10G Multi PoE+ L3 Switch 19", 4x 1/10GBase-X SFP+-Slots, managed L3, 24x 10/100/1000Base-T PoE+, OOB-Port (RJ-45), int. 100~240VAC (C14), console port (RJ-45)

24x RJ-45, 4x SFP+ Slots, 1x Console RJ-45, 1x OoB RJ-45, 1x USB-A, 1x SV

End of Life / Out of product range

MS400981M


Product is available

Order offer

MS400981M

28-Port 10G L2/L3 Switch 19" PoE+ fanless, 4x 1/10GBase-X SFP+-Slots, managed, 24x 10/100/1000Base-T PoE+, int. 100~240VAC (C14), Console port (RJ-45)

24x RJ-45, 4x SFP-Slots, 1x SV

End of Life / Out of product range

MS400970M


Product is available

Order offer

MS400970M

28-Port GbE Switch 19" Full-PoE++, 4x 1000Base-X SFP-Slots, managed, 24x 10/100/1000Base-T PoE++, 1900W, int. 100~240VAC (C14), Console Port (RJ-45)
