40G Multi 10G Fiber Switch 19" L3

40G Multi 10G Fiber Switch 19" L3

High performance 10G FTTO aggregation switch
Up to 24x 10G fiber connections with 2x 40G uplinks
High security through SSH, HTTPS, SNMPv3, Port Security 802.1x and full RADIUS NAC compatibility
Layer3 functionality, including RIP, OSPF
Standardized redundancy mechanism ERPS (G.8032.V2) for multi-FTTO ring topologies
Optimized cost per port solution on the central side of an FTTO network

Download

Data sheet MS400995M

Manuals MS400995M

Revit file (rfa) MS400995M

Secure Download

Firmware MS400995M

LV Text MS400995M

Visio MS400995M

Detail information

Description

The MS400995M is a L3 multi-10G fiber switch with a total of 26 physical fiber interfaces. 2 of the ports are designed as 40G uplink ports and 24 as 10G ports. The power supply is 230 VAC and can optionally be redundant.

The existing feature set (firmware) corresponds to the powerful hardware. Especially in the area of IT security, the MS400995M supports common IEEE standards for building secure and powerful IP networks.
Various standardized interfaces are available to provide management access for configuration or administration purposes

- CLI (sshv1 / sshv2)
- Web (http/https)
- SNMP (v1/v2c/v3)
- Serial interface RS-232 (outband, designed as RJ-45)

This switch can be used as an efficient distribution component in 10G FTTO infrastructures, especially in the central access area. The connection to the core system provides high performance and offers optional redundancy with 40G Ethernet.

In combination with the 10G Micro Switch from MICROSENS, cost-efficient high-performance networks with 10G up to the user can be established.
